SKU:CM2TTVHT
CM2TTVHT10 CHECK VALVE
Availability
+ 8 days
Availability
Inventory
+ 8 days lead time
Express delivery in 1–2 business days is available for part of this quantity. For more information, contact info@hydtec.com or call +46 304 400 400.
For lead time: Call the sales team tel. +46 304 400 400 or send an email to info@hydtec.com.
Couldn't load pickup availability
Technical specification
Technical specification
Application
Industrial Hydraulic
Body Material
Steel
Brand
Parker
Division (facet only)
Hydraulic Valve Systems Division Europe
Division id
687478
Maximum operating pressure
350 bar
Region
EU
Technology
Hydraulics
Url
Actuation type
Mechanical
Configuration
Check Valve in Port A
Cracking pressure
0.5 bar
Flow direction
Manifold to Directional Valve
Maximum flow rate
60 L/min
Maximum operating temperature
70 °C
Minimum operating temperature
-20 °C
Mounting type
Sandwich Plate
Port connection
NG06 / CETOP 03
Seal material
FPM
Weight
0.7 kg
Function
From directional valve to manifold, check valve in channel T
Mounting position
Unrestricted
For fluid type
Hydraulic Oil According to DIN 51524
Maximum ambient temperature
70 °C
Minimum ambient temperature
-20 °C
